MIL-DTL-3100H
TABLE II. Wheel assembly loads - 30 mph 1/ - Continued.
Assembly
Pounds per inch
120% load
Size (nominal)
Part number
of width
Total pounds (minimum)
26 x 6
7013976
480
3456
26 x 6
12290876
480
3456
28 x 2-3/4
10954693
530
1749
28 x 3
13211E9207
530
2099
32-1/4 x 3-1/2
10891631
630
2646
1/ Maximum speed or load shall not exceed the specified values by more than 5%
without contractor agreement.
3.5.2 Adhesion. Wheel assemblies shall exhibit complete adhesion of tire to wheel.
There shall be no areas of deficient adhesion. The load required to separate the tread from a
wheel shall be not less than 100 pounds per inch of width on any line of separation around the
circumference (see 4.6.5).
3.5.3 Ozone resistance. The elastomer used in solid tires shall evidence no cracks when
inspected at 7 power magnification per ASTM D1149 after being subjected to the tests specified
in 4.6.6.
3.6 Finish. Unless otherwise specified (see 6.2), portions of the wheel assembly not
covered by the elastomer shall be treated and painted in accordance with the manufacturer's
standard practice (see 4.6.2).
3.7 Identification and marking. Unless otherwise specified in the contract order
(see 6.2), the elastomer portion of the wheel assembly shall have the following information
molded or branded into only the outboard side of tire (see 4.6.2):
a.
Manufacturer's name or approval symbol.
b.
Military assembly part number.
c.
Wheel size: for example, 26 x 6.
d.
Construction identification (see 6.3).
e.
Week and year of manufacture (see 6.3.1).
f.
OZ (symbol to indicate ozone resistant).
3.8 Workmanship. Workmanship shall be such quality as to assure that solid-tired wheel
assemblies furnished under this specification are, and appear to be, free of defects (see 4.6.2).
4. VERIFICATION
4.1 Inspection equipment. Inspection equipment must be capable of repetitive
measurements to an accuracy of 10 percent of the measurement tolerance.
7
