MIL-DTL-3100H
4.5.1 Sampling. Unless otherwise specified (see 6.2), samples for examination and tests,
from an inspection lot, shall be selected in accordance with ANSI/ASQC Z1.4. A minimum of
three specimens shall be required for tests.
4.5.2 Examination. Samples shall be examined for defects in accordance with table IV.
Any redesign or modification of the contractor's standard to comply with specified requirements
shall receive particular attention for adequacy and suitability. This element of inspection shall
encompass all visual examinations and dimensional measurements of requirements of section 3 as
listed in table IV. Noncompliance with any specified requirement or presence of one or more
defects preventing or lessening maximum efficiency shall constitute cause for rejection. The
sample units shall be examined for the defects specified in table IV.
TABLE IV. Classification of defects.
Method of
examination
Category
Defect
Critical
None
Major:
101
Tire dimensions affecting interchangeability, out of
Visual and
SIE 1/
tolerance (see 3.3).
102
Wheel dimensions affecting interchangeability, out of
Visual and
tolerance (see 3.3).
SIE
103
Open splice tire (see 3.3).
Visual
104
Identification marking, improper (see 3.7).
Visual
105
Faulty workmanship affecting performance (see 3.8).
Visual
Minor:
201
Tire dimensions not affecting interchangeability, out of
Visual and
tolerance (see 3.3).
SIE
202
Wheel dimensions not affecting interchangeability, out of
Visual and
tolerance (see 3.3).
SIE
203
Chips, cuts, or blisters on tire (see 3.3).
Visual
204
Poor buff on tire (see 3.3).
Visual
205
Flow cracks on tire (depth over 1/32 inch) (see 3.3).
Visual and
SIE
206
Edge separation of tire (may be buffed out if not more
Visual and
than 1/8 inch under body of tire (see 3.3).
SIE
207
Wheel finish not as specified (see 3.6).
Visual
208
Improper or incomplete marking of tire (see 3.7).
Visual
209
Faulty workmanship on wheel assembly (see 3.8).
Visual
1/ SIE = Standard Inspection Equipment.
